Technical parameters:
| External size (LxWxH) | 2150×1060 mm |
| Mattress platform | 1925×880 mm |
| Safe working load | 250kg |
| Height adjustment | 350-800 mm |
| Back-rest adjustment | 0-75° (±10°) |
| Knee-rest adjustment | 0-35° (±10°) |
| Reverse Trendelenburg | 0-16° |
| Trendelenburg | 0-16° |
| Angle indicator | 0-90° |
| Auto-regression | 100+60 mm |
| Position line | 30° |
| Voltage and frequency | 100-240V · 50/60Hz |
| Plug as required (hospital grade) |
Optional:
| Weighing System |
| Bed extension 200mm |
| Back-up battery |
| Nurse Control Panel |
| Emergency Stop Button |
| Cardiac Chair Position |
| Directional wheels function |
| 5th and 6th Extra Side Rail For Full Protection |
| Monkey Pole |
| Balkan Frame |
| Linen Holder |
| One-button for patient mobilisation position |
| One button nursing position |
| Lowest position indicator |
Technical configuration:
| Linear motor | 4pcs |
| 5” double side castors, central locking system | 4pcs |
| ABS oasis side rail extra height | 1set |
| ABS oasis bed ends with safe lock | 1set |
| PP bed platform, removable & washable | 9 pcs |
| Plastic socket inside PP guardrail for phone or glasses | 2pcs |
| Patent angle indicator for back-rest and trendelenburg position | 4pcs |
| Ø70mm wall bumper wheel | 4pcs |
| Central locking pedal | 2pcs |
| ABS mattress stopper | 2pcs |
| Hand controller | 1 pc |
| Manual CPR | |
| Electric CPR |
